The MG type European standard gantry crane with hook is designed and manufactured by European FEM advanced standard. Compared to general MG type crane. its rated capacity is 3~20t, the main feature of is characterized by European trolley. The whole trolley has reducer hard tooth surface. three-in-one drive. adopted PLC+ frequency conversion technology, which comprehensively improves the whole performance of the product, while the overall weight of the crane lighten more than 15% and the wheel press 10~20%. This product can widely used in factory, freight yard. warehouse and other places for cargo handling.
| Capacity (ton) | 5 | 10 | 16/3.2 | 20/5 | 32/5 | 50/10 | ||
| Span (m) | 18, 22, 24, 26, 30, 35 | |||||||
| Lifting height (m) | 10, 11, 12 | |||||||
| Working class | A5 | |||||||
| Control way | Cabin control or remote control | |||||||
| Power source | 380V 50HZ 3phase (Could supply it as yours) | |||||||
| Trolley lifting mechanism | ||||||||
|
Lifting speed
(m/min)
|
Main hook | 11.3 | 8.5 | 7.9 | 7.2 | 7.5 | 5.9 | |
| Auxiliary hook | - | - | 14.6 | 15.4 | 15.4 | 10.4 | ||
| Trolley traveling mechanism | ||||||||
| Traveling speed (m/min) | 37.3 | 35.6 | 36.6 | 36.6 | 37 | 36 | ||
| Crane traveling mechanism | ||||||||
| Traveling speed (m/min) | 37.3 | 39.7 | 37.3 | 39.7 | 39.4 | 38.5 | ||
| Motor power(KW) | 40.8-51.8 | 41.5-52.8 | 80-77 | 84-81 | 99.3-117.3 | 126.5 | ||
| Steel track recommended | 43kg/m | 43kg/m or QU70 | ||||||
